KLAUKE 586R10 Conector de cravação de redução, alumínio para cobre, 50 mm² para 35 mm², estanhado, 46 mm

The KLAUKE 586R10 is a high-quality reducing crimp connector designed for reliable and durable connections between aluminium and copper conductors. Ideal for electrical installations up to 1 kV, this connector ensures low resistance and long-term stability. The tin-plated copper insert prevents galvanic corrosion, making it suitable for demanding environments.

Advantages

• Reliable transition between aluminium and copper conductors
• Tin-plated copper insert prevents corrosion
• Complies with DIN 46267 Part 1 for safety and performance
• Suitable for operating temperatures from -40°C to +90°C

Suitable for

• Power distribution systems
• Industrial electrical installations
• Connecting aluminium cables to copper terminals
• Applications requiring a reduction from 50 mm² to 35 mm²

Key specifications

• Connector Type: Reducing Crimp Connector
• Conductor Material Compatibility: Aluminium to Copper
• Conductor Cross-Section (Input): 50 mm²
• Conductor Cross-Section (Output): 35 mm²
• Connector Body Material: Aluminium
• Insert Material: Copper, Tin-Plated
• Connection Method: Crimp
• Insulation: Uninsulated
• Overall Length: 46 mm
• Outer Diameter: 16.5 mm
• Voltage Rating: Up to 1 kV
• Standard Compliance: DIN 46267 Part 1
• Operating Temperature Range: -40°C to +90°C

Recommendations

For optimal performance, use with appropriate crimping tools and ensure clean conductor surfaces. Always follow manufacturer guidelines for installation.
