Mecanismo de interruptor de luz KONTAK-SIMON Simon 54 branco 1 módulo 1 via 10AX 250V sem parafusos

Traditional screw terminals can make switch installation slow and prone to loose connections over time. The KONTAK-SIMON Simon 54 switch mechanism eliminates this hassle with screwless quick-connect terminals that grip conductors firmly in seconds. This single-pole rocker switch handles 10 AX at 250 V AC, making it ideal for controlling lighting circuits in homes, offices, and commercial spaces. Its compact 1-module design fits standard flush boxes and pairs with compatible frames and cover plates from the Simon 54 series.

Who is it for

Electricians and DIY installers who value speed and reliability. It suits anyone upgrading or installing light switches in residential or commercial interiors where a clean white finish and robust performance are required.

Main features

• Screwless quick-connect terminals for fast, secure wiring
• Rated 10 AX / 250 V AC for lighting and small motor loads
• Single-pole (1-way) rocker mechanism with crisp on/off action
• Flush mounting in a standard 1-module box
• Durable white thermoplastic housing (PC/ABS)
• IP20 protection for indoor use
• Mechanical endurance of 40,000 switching cycles
• Complies with CE and PN-EN 60669-1 standards

Specifications

• Brand: KONTAK-SIMON
• Model: CW5C.01/11
• MPN: CW5C.01/11
• EAN: 5902787900328
• Series: Simon 54
• Product type: Light switch mechanism
• Switch type: Single pole (1-way)
• Actuation: Rocker
• Current rating: 10 AX
• Voltage rating: 250 V AC
• Connection type: Quick connection (screwless terminals)
• Terminal capacity: 2 x 2.5 mm²
• Number of modules: 1
• Mounting type: Flush mounting
• Material: Thermoplastic (PC/ABS)
• Colour: White
• IP rating: IP20
• Operating temperature: -5 to +35 °C
• Mechanical endurance: 40,000 cycles
• Standards: CE, PN-EN 60669-1
• Application: Indoor residential & commercial
• Installation: Requires flush box and compatible frame/cover plate (sold separately)

Tips

For a complete installation, order a matching Simon 54 frame and cover plate. Ensure the flush box is properly aligned and the circuit is de-energized before wiring. Use solid or stranded conductors up to 2.5 mm² for optimal terminal grip.
