LAPP L-RA 48 V Conector fêmea circular reto, 3 polos, ligação por parafuso, IP67, vermelho 61794955

Industrial circular connector with a robust polyamide housing and brass contacts, delivering dependable 48 V / 10 A power and signal transmission in demanding environments. Its straight female design with screw terminals ensures secure, vibration-resistant wiring and quick field installation.

Advantages

The L-RA series combines IP67 protection against dust and water with a UL94 V-0 flammability rating, making it suitable for both indoor and outdoor applications. The M16 cable gland provides strain relief and maintains the seal, while the red housing offers high visibility for safety and identification. Screw termination allows tool-free assembly and reliable connections even with stranded conductors.

Suitable for

• Industrial automation and control systems
• Power distribution in machinery and equipment
• Outdoor installations requiring weatherproof connectors
• Applications with frequent mating cycles where durability is essential

Key specifications

• Series: L-RA
• Gender: Female, straight orientation
• Number of poles: 3
• Rated voltage: 48 V, rated current: 10 A
• Contact material: Brass; housing material: Polyamide
• Termination: Screw terminal
• Cable gland thread: M16
• Ingress protection: IP67
• Operating temperature: -25°C to +70°C
• Flammability rating: UL94 V-0

Recommendations

For optimal performance, use with cables having an outer diameter within the M16 gland range and ensure proper torque on screw terminals. Pair with a compatible L-RA male connector to complete the connection.
