Módulo Central LEAN CARS CSR-12T-2A para Sistema de Controlo de Acesso Satel ACCO NET

When network connectivity fails, centralized access management can grind to a halt. The LEAN CARS Central Module CSR-12T-2A keeps access control running by storing events locally and managing up to two doors and two readers, ensuring uninterrupted operation even during outages.

Who is it for

Security integrators, facility managers, and businesses needing a scalable, Ethernet-connected access control solution with high user capacity and flexible input/output configuration will find this module ideal. It suits office buildings, warehouses, and industrial sites where dependable access management is critical.

Main features

• Controls 2 doors and supports 2 readers (Wiegand 26-66 bit or DALLAS)
• 12 programmable inputs (NO, NC, EOL, 2EOL/NO, 2EOL/NC) for versatile sensor integration
• 2 programmable outputs (relay and OC) for locking devices or alarms
• Supports up to 131,072 users and logs 250,000 events locally
• Built-in clock with battery backup and local memory for offline operation
• Ethernet (RJ-45) communication for network integration and firmware updates
• Tamper protection via enclosure tamper input
• DIN rail or screw mounting for flexible installation

Specifications

• System compatibility: Satel ACCO NET Access Control System
• Power supply: 12 V DC
• Max current consumption: 200 mA
• Operating temperature: -10°C to +55°C
• Humidity range: 10-90% (non-condensing)
• Protection grade: IP20
• Mounting: DIN rail or screw mounting

Tips

For best results, mount the module in a secure enclosure and ensure proper ventilation.
