Holofote LED OEM VISIONAL VS-FL-24-PIR-IP44/W — 24 W, 2880 lm, sensor PIR, IP44

OEM VISIONAL VS-FL-24-PIR-IP44/W is a 24 W LED floodlight that delivers 2880 lm of cool white light (6000 K). The fixture includes a built-in PIR motion sensor and has IP44 protection, making it suitable for outdoor and covered indoor areas where motion-activated, energy-efficient lighting is required. Its compact round form (Ø300×25 mm) and wide input voltage range (AC 170–265 V) allow use on entrances, driveways, gardens and other similar locations.

Advantages

The LED floodlight provides high luminous efficacy with 2880 lm output from 24 W, reducing energy consumption compared with conventional lighting. The integrated PIR sensor enables automatic motion detection to activate illumination only when needed. IP44 rating protects the luminaire against splashing water and solid objects over 1 mm, suitable for exposed but sheltered outdoor positions. The wide voltage range (AC 170–265 V) ensures compatibility with common mains supplies.

Suitable for

• Entrance and porch lighting
• Driveways and pathways
• Garden and yard illumination
• Security and motion-activated outdoor lighting

Key specifications

• Power consumption: 24 W
• Luminous flux: 2880 lm
• Light colour temperature: 6000 K (cool white)
• Voltage: AC 170–265 V
• Dimensions: Ø300 × 25 mm
• Sensor: Built-in PIR motion sensor
• Ingress protection: IP44
• Manufacturer part number (MPN): VS-FL-24-PIR-IP44/W

How to use

Mount the floodlight on a stable surface using appropriate fasteners for the installation location and ensure the unit is positioned to cover the desired detection area. Connect to the mains supply (AC 170–265 V) following local electrical regulations and disconnect power before wiring. Adjust the sensor orientation if needed so the PIR detector faces the expected movement direction. After installation, power up and verify that the PIR sensor activates the lamp when motion is detected.

Recommendations

For reliable operation, install the luminaire under slight shelter to reduce direct exposure to heavy rain despite its IP44 rating. Avoid mounting the sensor near heat sources or air vents that may cause false triggers. Periodically check electrical connections and clean the sensor and lens to maintain optimal detection and light output.
