Leitor de cartões Akasa AK-CR-03WHV2 USB 3.0 branco, leitor multi-slot externo para SD/microSD/CF/Memory Stick

This portable plug-and-play card reader enables use of chip cards with desktop PCs, laptops and Mac computers. It is designed for online banking, digital signature with ID cards and other chip card applications, and supports multiple chip card protocols for broad compatibility.

Advantages

The external USB-powered reader offers plug-and-play operation and is compatible with the Microsoft USB-CCID driver. Available in black or white, it provides LED indication for power and card presence and connects via USB 2.0 (backward compatible with 1.1/1.0) for straightforward installation and use.

Suitable for

• Online banking with chip cards
• Digital signing using ID cards
• Access control and smart card authentication
• Use on desktops, laptops and Mac computers

Key specifications

• Interface: USB 2.0 (compatible with 1.1/1.0)
• Data transfer rate: 480 Mb/s
• Supported protocols: T0, T1
• Supported cards: I2C memory cards (SLE4418, SLE4428, SLE4432, SLE4442, SLE4436, SLE5536, SLE6636), AT88SC1608, AT45D041; AT45DB041 via external EEPROM; ISO7816 Class A/B/C (5V/3V/1.8V); Military Common Access Card
• LED indicators: Blue (power), Red (card inserted)
• Power: USB powered
• Compatibility: Microsoft USB-CCID driver compatible
• Dimensions: 65 x 60 x 18 mm

How to use

Connect the reader to an available USB port on your PC, laptop or Mac. The device uses USB power and supports plug-and-play operation with Microsoft USB-CCID driver compatibility; after connecting, insert the chip card into the reader until the red LED indicates card presence. Use your operating system or card application to access functions such as online banking or digital signatures.

Recommendations

For reliable operation, use supported chip card types and ensure your system has the appropriate drivers installed. Protect the reader and cards from excessive moisture and mechanical stress; disconnect the reader from the USB port before cleaning or when not in use for extended periods.
