LevelOne fonte de alimentação industrial 48V DC, 48V DC, 40W, calha DIN

LevelOne fonte de alimentação industrial 48V DC, 48V DC, 40W, calha DIN
LevelOne fonte de alimentação industrial 48V DC, 48V DC, 40W, calha DIN
117,99 €
The POW-4811 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guara... Ler mais
Stock 1 Código 2399286 Marca LEVELONE Modelo POW-4811 Garantia 2 anos

Envios e devoluções

Entrega prevista Sexta-feira, Outubro 23
Receberá atualizações através do nosso sistema de seguimento detalhado
Opções de pagamento
Cartão bancárioVisaMastercardPayPalApple PayGoogle PayTransferência bancária
The POW-4811 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.

LevelOne 48V DC Industrial Power Supply, 48V DC, 40W, DIN-Rail. Total power: 39.8 W, AC input voltage: 85 - 264 V, Peak power: 40 W. Mean time between failures (MTBF): 301700 h. Product colour: Blue, White. Safety: UL508, TUV EN60950-1 Approved,EN55011, EN55022 (CISPR22), EN61204-3 Class B,EN61000-4-2, 3, 4, 5,.... Width: 90 mm, Depth: 40 mm, Height: 100 mm

Destaques principais
  • Universal AC Input at Full Range
  • Short Circuit, Overload / Over Voltage Protection
  • Fanless Design
  • Supports DIN-rail installation
  • 100% Full Load Burn-in Test
  • DC OK Relay Contact
Especificações
Altura
100 mm
Altura da embalagem
40 mm
Características técnicas
48V DC Out
Código do Sistema Harmonizado (HS)
84733020
Conectores de alimentação periféricos (Molex) (4 pinos)
0
Cor do produto
Blue, White
Corrente máxima
0.83 A
Funções de proteção elétrica
Over voltage, Overload, Short circuit
Humidade relativa de funcionamento (H-H)
20 - 90%
Indicadores LED
Yes
Largura
90 mm
Largura da embalagem
90 mm
País de origem
China
Peso
300 g
Peso da embalagem
350 g
Potência de pico
40 W
Potência total
39.8 W
Profundidade
40 mm
Profundidade da embalagem
100 mm
Segurança
UL508, TUV EN60950-1 Approved,EN55011, EN55022 (CISPR22), EN61204-3 Class B,EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, EN61000-6-2, EN61204-3 heavy
Temperatura de funcionamento (T-T)
-20 - 70 °C
Tempo médio entre falhas (MTBF)
301700 h
Tensão de entrada CA
85 - 264 V

Folheto

Abrir documento
Histórico de preços nos últimos 6 meses
LevelOne fonte de alimentação industrial 48V DC, 48V DC, 40W, calha DIN
Atual
117,99 €
Mais baixo
117,07 €
Mais alto
123,67 €
Variação 24 h
+0,92 €   +1%
Semana
+0,68 €   +1%
Mês
-0,75 €   -1%
