Lima Bahco ERGO 4-138-08-1-2

The BAHCO File ERGO 4-138-08-1-2 is a flat mill file with a bastard cut and a rounded edge, engineered for efficient material removal and shaping. It measures 20 mm in width and 3.5 mm in thickness, and weighs 160 g. The file features a dual-component ERGO™ handle designed to provide a secure grip and improved control for metalworking and woodworking tasks.

Advantages

The dual-component handle offers enhanced grip and reduced slippage, while the bastard cut provides a balance between cutting speed and surface finish. The rounded edge allows work on curved surfaces and chamfers. Compact dimensions and moderate weight make the file easy to handle during precision tasks.

Suitable for

• General metal filing and deburring
• Shaping and fitting in woodworking
• Finishing curved edges and chamfers
• Maintenance and repair tasks requiring controlled material removal

Key specifications

• Brand: BAHCO
• Model / MPN: 4-138-08-1-2
• Type: Flat mill file, bastard cut, round edge
• Width: 20 mm
• Thickness/Height: 3.5 mm
• Weight: 160 g
• Handle: Dual-component ERGO™ handle
• EAN: 7311518000615

How to use

Secure the workpiece before filing. Hold the ERGO™ handle with a comfortable grip and apply even forward strokes along the file's length; lift the file on the return stroke to avoid dulling the teeth. Use the flat surface for general flattening and the rounded edge for curved profiles or chamfers. Clean the file teeth regularly with a file card to maintain cutting efficiency.

Recommendations

For best results, use light to moderate pressure and maintain a consistent filing angle; select a coarser or finer file depending on the material and desired finish. Store the file dry and protected from impacts to preserve the cutting teeth and handle.
