LogiLink FB4LC40 Caixa de terminação FTTH com 2x LC/APC duplex e 40 m de cabo pré-montado

The LogiLink FB4LC40 stands out as a professional-grade FTTH termination box that arrives with a 40-metre pre-terminated cable, eliminating the need for on-site fibre splicing. Unlike basic termination boxes that require additional connectors and tools, this unit is ready for immediate deployment in fibre-to-the-home networks. The integrated 2x LC/APC duplex adapter ensures low-loss connections, while the bend-insensitive G.657.A2 fibre maintains signal integrity even in tight installation spaces.

Highlights

• Pre-terminated 40 m cable with LC/APC connectors on both ends for plug-and-play installation
• 2x LC/APC duplex adapter with insertion loss ≤ 0.3 dB and return loss ≥ 60 dB
• Bend-insensitive single-mode fibre (G.657.A2) for reliable performance in constrained routing
• Compact ABS housing, wall-mountable, suitable for indoor FTTH termination
• Wide operating temperature range from -20°C to +70°C

In daily use

Installers appreciate the time savings: simply mount the box, route the pre-terminated cable to the optical network terminal, and connect. The white ABS housing blends discreetly into residential or office environments. The LC/APC connectors ensure low back reflection, critical for high-speed GPON and XGS-PON services. The 3.0 mm cable diameter is robust yet flexible, making it easy to handle in conduits or along baseboards.

Full specifications

• Product type: FTTH termination box
• Connector type: 2x LC/APC duplex
• Fibre type: Single-mode G.657.A2 (bend-insensitive)
• Included cable length: 40 m
• Included cable connector: LC/APC to LC/APC
• Number of fibres: 2
• Insertion loss: ≤ 0.3 dB
• Return loss: ≥ 60 dB
• Operating temperature: -20°C to +70°C
• Housing material: ABS plastic
• Mounting type: Wall-mountable
• Colour: White
• Cable diameter: 3.0 mm

Final note

For FTTH deployments where speed and reliability matter, the LogiLink FB4LC40 delivers a complete, factory-terminated solution that reduces installation errors and ensures consistent optical performance.
