Luminária de sistema LED Rittal SG 2372.102 — indicador LED encastrável, cores: verde/vermelho/amarelo, 1 unid.

Rittal SG 2372.102 is an LED panel indicator designed for mounting in control cabinets and machine panels. Available as a single-unit LED module in green, red or yellow, this compact signalling device provides clear visual indication of operating states, alarms and process steps in industrial environments. The lightweight construction and standard panel-mount design allow integration into existing housings and signal pillar systems where three standard colours are required.

Advantages

The LED indicator delivers immediate, easy-to-read status information with low power consumption and long service life typical of LED technology. Its compact form factor and simple electrical connection support straightforward installation and maintenance. Colour-coded signalling enhances operator response time and reduces ambiguity in multi-state systems.

Suitable for

Key specifications

How to use

Install the LED module into the prepared panel cut-out and secure according to cabinet manufacturer guidelines. Connect the electrical supply and signal lines following the wiring diagram for the specific control circuit and observe polarity where applicable. Configure the control system so that each colour corresponds to the required machine state or alarm condition. Perform a functional test after installation to verify illumination and correct colour assignment.

Recommendations

For reliable operation, use the LED indicator within its specified electrical and environmental limits, ensure secure wiring and protect against excessive mechanical stress. Combine with other Rittal signal components for modular signalling solutions and plan colour assignment consistently across panels to avoid operator confusion.
