Mecanismo de botão Schneider Electric Merten System M 1 função 10A 250V AC branco

The Schneider Electric MTN6500-0101 is a high-quality push-button mechanism from the Merten System M design line, designed for flush-mounted installation. This 1-gang momentary action switch features a normally open (NO) contact, rated at 10A and 250V AC, making it ideal for controlling lighting and other electrical loads in residential and commercial buildings. Manufactured from durable thermoplastic (PC) with IP20 protection, it ensures reliable performance and long service life.

Advantages

This push-button mechanism offers easy installation with screw or claw fixing and screw terminals for secure wiring. Its compact design fits standard flush-mounted boxes, and the thermoplastic material provides excellent insulation and impact resistance. The mechanism is VDE and CE certified, complying with EN 60669-1 and IEC 60669-1 standards, ensuring safety and reliability.

Suitable for

• Lighting control in living rooms, offices, and corridors
• Momentary switching applications (e.g., doorbells, buzzers)
• Integration with Merten System M switch ranges and frames
• New installations and retrofits in flush-mounted systems

Key specifications

• Product Type: Push-button mechanism
• Contact Configuration: 1 Normally Open (NO)
• Rated Current: 10 A
• Rated Voltage: 250 V AC
• Frequency: 50/60 Hz
• Mounting: Flush-mounted
• Fixing: Screw or claw fixing
• Terminal Type: Screw terminals
• Terminal Capacity (Rigid): 2 x 2.5 mm²
• Terminal Capacity (Flexible): 2 x 1.5 mm²
• Material: Thermoplastic (PC)
• IP Degree: IP20
• Design Line: Merten System M
• Operating Temperature: -5 to 40 °C
• Storage Temperature: -5 to 50 °C
• Relative Humidity: 5-95%
• Standards: EN 60669-1, IEC 60669-1
• Certifications: VDE, CE
• Function: Momentary action
• Number of Gangs: 1-gang

Recommendations

For a complete installation, pair this push-button mechanism with a compatible Merten System M frame and rocker. Ensure the load does not exceed the rated current and voltage. Suitable for use with standard 60mm flush-mounted boxes.
