Mecanismo de interruptor de tecla GIRA 0215723 1 polo 2 vias 10A 250V AC, encastrar, terminais de parafuso, System 55

The GIRA 0215723 rocker switch insert stands out as a core component of the modular System 55 range, offering a robust 10 A switching capacity in a compact, flush-mounted design. Unlike integrated switches, this insert is intended for combination with a separately selected rocker and cover frame, allowing you to match the surrounding décor precisely while maintaining consistent electrical performance. Its 1-pole, 2-way (changeover) configuration makes it suitable for both simple on/off control and two-way switching circuits, providing flexibility in lighting and general load management.

Highlights

• 1-pole, 2-way (changeover) switching function for versatile circuit designs
• Rated at 10 A / 250 V AC, suitable for lighting and general loads
• Flush-mounted installation with screw terminals for secure wiring
• Compatible with Gira System 55 frames and rockers (sold separately)
• Halogen-free thermoplastic construction, VDE certified

In daily use

Installed behind a matching Gira rocker and frame, this insert provides reliable switching for residential or commercial spaces. The screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring a firm connection. Its IP20 rating is appropriate for indoor dry locations. The changeover contact allows the insert to be used as a standard switch or as part of a two-way circuit (e.g., controlling a light from two positions). Because the rocker and frame are separate, you can later change the aesthetic without replacing the electrical mechanism.

Full specifications

• Brand: GIRA
• Model: 0215723
• MPN: 0215723
• EAN: 4010337068693
• Switch type: Rocker switch insert
• Switch function: 1-pole, 2-way (changeover)
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection type: Screw terminals
• Mounting type: Flush-mounted (Unterputz)
• System compatibility: Gira System 55
• Material: Thermoplastic
• Protection class: IP20
• Number of terminals: 3
• Operating temperature range: -20 to +40 °C
• Halogen-free: Yes
• Certification: VDE
• Conductor cross-section (rigid): 1.5 - 2.5 mm²
• Installation depth: Approx. 32 mm
• Suitable for: Lighting and general switching applications
• Requires rocker: Yes (sold separately)
• Requires frame: Yes (sold separately)

Final note

For a complete installation, pair this insert with a Gira System 55 rocker and cover frame of your choice. The insert itself is the reliable core that ensures long-term switching performance.
