METZ CONNECT 11051005 módulo keystone RJ45 Cat.6A blindado, sem ferramentas, preto/laranja

For network installations where reliability and performance are non-negotiable, the METZ CONNECT 11051005 stands apart with its die-cast zinc housing and fully shielded Cat.6A design. Unlike plastic modules that flex under repeated use, this keystone jack delivers stable 10-Gigabit Ethernet in a compact, tool-free package that installs in seconds without sacrificing signal integrity.

Highlights

• Cat.6A performance supports 10GBASE-T up to 500 MHz
• 360° shielded die-cast zinc housing for superior EMI protection
• Tool-free termination with LSA punch-down blocks – no special tools required
• Supports PoE+ and 4PPoE (IEEE 802.3at/bt) for power-hungry devices
• Gold-plated contacts ensure long-term corrosion resistance and reliable connectivity
• Compact dimensions (15.5 x 65 x 75 mm) fit standard keystone faceplates and patch panels

In daily use

Whether you're wiring a high-density office, an industrial control cabinet, or a home network with future-proofing in mind, this module handles the load. The black and orange colour coding simplifies port identification, while the 180° straight connection angle keeps cable routing neat. With an operating temperature range of -20 °C to 55 °C, it performs in environments where lesser components fail.

Full specifications

• Brand: METZ CONNECT
• Model: 11051005
• MPN: 11051005
• EAN: 4250184122319
• Product type: RJ45 keystone module
• Category: Cat.6A
• Shielding: Shielded (die-cast zinc housing)
• Connector type: RJ45
• Module design: Keystone
• Connection angle: 180°
• Wiring standard: T568A/B
• PoE support: PoE+ / 4PPoE (IEEE 802.3at/bt)
• Installation: Tool-free (LSA punch-down)
• Contact plating: Gold over nickel
• Max AC voltage: 250 V
• Max current: 8 A
• Operating temperature: -20 °C to 55 °C
• Standards compliance: ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.2
• Dimensions (W x D x H): 15.5 x 65 x 75 mm
• Weight: 95 g

Final note

For installers and IT professionals, the METZ CONNECT 11051005 delivers the durability and performance required for today's high-speed networks, all in a compact, easy-to-install form factor.
