METZ CONNECT 142M4D25050 Cabo de ligação Industrial Ethernet M12, CAT 5e S/UTP, 5 m, bainha PUR verde, resistente a ácidos/ozono/UV, adequado para correntes de arrasto

Engineered for harsh industrial environments, this METZ CONNECT M12 patch cable delivers reliable 10/100 Mbps Ethernet connectivity over a 5-meter length. With its rugged PUR jacket and M12 D-coded connectors, it withstands acids, ozone, UV radiation, and constant flexing in drag chains, ensuring uninterrupted data transmission in automation and machine vision applications.

Overview

The METZ CONNECT 142M4D25050 is a CAT 5e S/UTP industrial Ethernet patch cable terminated with M12 D-coded male connectors on both ends. Its 4-pin D-coded assignment supports Fast Ethernet (10/100 Mbps) for industrial protocols. The green polyurethane (PUR) jacket offers superior resistance to chemicals, oils, ozone, and UV light, making it ideal for outdoor and harsh indoor use. The cable is also halogen-free and drag chain compatible, allowing continuous flexing without performance degradation.

What stands out

• Durable PUR jacket: acid-resistant, ozone-resistant, UV-resistant, and oil-resistant for long service life in demanding conditions.
• Drag chain compatible: designed for continuous flexing, suitable for moving machinery and robotic applications.
• Secure M12 D-coded connectors: IP67 rated when mated, ensuring reliable connections in wet or dusty environments.
• Industrial-grade performance: CAT 5e S/UTP with copper conductors delivers stable 10/100 Mbps data transfer.
• Wide operating temperature range: from -20°C to +80°C, suitable for extreme conditions.

Technical details

• Cable type: M12 Industrial Ethernet Patch Cable, CAT 5e
• Shielding: S/UTP (overall braid shield, unshielded twisted pairs)
• Connectors: M12 D-coded male to M12 D-coded male, 4-pin
• Length: 5 m
• Jacket material: PUR (polyurethane), green
• Data transfer rate: 10/100 Mbps (Fast Ethernet)
• Conductor material: copper
• Operating temperature: -20°C to +80°C
• IP rating (mated): IP67
• Halogen-free: Yes
• Oil resistance: Yes

Our verdict

For industrial automation engineers seeking a robust, reliable Ethernet connection in challenging environments, the METZ CONNECT 142M4D25050 is an excellent choice. Its combination of rugged PUR jacket, M12 connectors, and drag chain capability ensures long-term performance with minimal maintenance.
