Midspan PoE AXIS TU8007-R 90 W IEEE 802.3bt Type 4

The AXIS TU8007-R is a high-performance Power over Ethernet (PoE) midspan injector designed to deliver up to 90 W of power per port, compliant with IEEE 802.3bt Type 4 standard. Ideal for powering demanding devices such as PTZ cameras, access control systems, and wireless access points, this unit ensures reliable and efficient power delivery over existing Ethernet cabling.

Advantages

With its robust metal enclosure and wide operating temperature range from -40 °C to 65 °C, the AXIS TU8007-R is built for harsh environments. It supports Gigabit Ethernet data rates (10/100/1000 Mbps) and features overload, short-circuit, and over-voltage protection for enhanced safety. The compact design allows for flexible wall or shelf mounting.

Suitable for

• Powering high-power PoE devices such as PTZ cameras, video encoders, and wireless access points
• Industrial and outdoor installations requiring extended temperature tolerance
• Network upgrades to IEEE 802.3bt Type 4 without replacing existing switches

Key specifications

• PoE Standard: IEEE 802.3bt Type 4
• PoE Power Output: 90 W per port
• Ethernet Data Rate: 10/100/1000 Mbps
• Number of PoE Ports: 1
• Input Voltage: 100-240 V AC, 50/60 Hz
• Operating Temperature: -40 °C to 65 °C (-40 °F to 149 °F)
• Connectors: 2x RJ-45 (Data In, PoE Out), 1x IEC C14 (AC Power)
• Mounting: Wall mount, Shelf mount
• Enclosure Material: Metal
• Certifications: CE, FCC, VCCI, RCM, KC, UL

Recommendations

For optimal performance, use with CAT5e or higher cabling. Ensure the power source is stable and within the specified input range. The AXIS TU8007-R is an ideal solution for expanding PoE capabilities in existing networks.
