Mini PC Acer Revo Box RB102-RPL Intel Core 5 120U 16 GB 512 GB SSD Windows 11 Branco (DT.BRFEG.008)

The Acer Revo Box RB102-RPL is a compact white mini PC built around the energy-efficient Intel Core 5 120U processor, paired with 16 GB of DDR4 memory and a fast 512 GB M.2 PCIe NVMe SSD. Running Windows 11, it delivers responsive everyday performance in a footprint small enough to sit on a desk, mount behind a monitor or tuck into a media setup.

Advantages

The 10-core Intel Core 5 120U (2 performance + 8 efficient cores, 12 threads, up to 5.0 GHz) balances responsiveness with low power draw, making the Revo Box quiet and economical to run. DDR4-3200 memory and an NVMe SSD keep the system snappy when booting, launching applications and multitasking. Integrated Intel Graphics drives dual displays, and the chassis includes dual Gigabit Ethernet plus Wi-Fi 6 and Bluetooth for flexible wired and wireless connectivity. A bundled VESA bracket lets you mount the unit out of sight behind a compatible display.

Suitable for

• Home and office productivity, web and email
• Digital signage and kiosk deployments
• Behind-the-monitor or media-centre installations
• Space-constrained workspaces needing dual-LAN networking

Key specifications

• Brand: Acer
• Model: Revo Box RB102-RPL
• MPN: DT.BRFEG.008
• EAN: 4711474841827
• Form factor: Mini PC
• Processor: Intel Core 5 120U, 10 cores (2P + 8E) / 12 threads, 1.4 GHz base, up to 5.0 GHz
• Memory: 16 GB DDR4-3200 (2x SO-DIMM, expandable to 32 GB)
• Storage: 512 GB M.2 PCIe NVMe SSD
• Graphics: Integrated Intel Graphics
• Operating system: Windows 11 (64-bit)
• Rear ports: 2x USB-A 3.0, 1x HDMI, 1x DisplayPort, 2x Gigabit Ethernet (RJ-45)
• Front ports: 1x USB-C 3.1 (10 Gbit/s), 2x USB-A 3.1 (10 Gbit/s), 1x 3.5 mm audio jack
• Wireless: Wi-Fi 6 (802.11ax), Bluetooth 5.0
• Mounting: VESA 100 x 100 bracket included
• Dimensions: 131 x 131 x 43 mm; Weight: approx. 0.9 kg
• Colour: White

How to use

Mount the Revo Box behind a display with the supplied VESA bracket or place it on a desk, then connect a monitor via HDMI or DisplayPort, attach a keyboard and mouse to the USB ports and plug in the network cable or join a Wi-Fi network. Power on and complete the Windows 11 first-run setup, then install updates and any required drivers from Windows Update or Acer support.

Recommendations

Leave the ventilation slots clear for steady airflow, keep Windows and drivers up to date, and use the second Ethernet port for redundant or segmented networking where dual-LAN is useful.
