MITON MT-P1280 Caixa de Derivação de Sobrepor, IP54, Cinzento (RAL 7035), 128x80x50 mm

The MITON MT-P1280 is a high-quality surface-mounted junction box designed for electrical installations, junctioning, and protecting connections. Made from durable polypropylene (PP) with an IP54 rating, it offers reliable protection against dust and water splashes, making it suitable for indoor and outdoor use. The box features 8 flexible membrane cable entries, a screw-on lid, and a compact size of 128x80x50 mm. Its grey colour (RAL 7035) blends seamlessly with standard electrical environments.

Advantages

Robust polypropylene construction ensures long-lasting durability. IP54 ingress protection safeguards against dust and water. Flexible membrane glands allow easy cable entry without additional fittings. Screw-on lid provides secure closure. Halogen-free and glow-wire tested to 650°C for enhanced safety. Impact resistance IK07 withstands mechanical stress. Rated insulation voltage 400 V suitable for various electrical applications.

Suitable for

• Electrical junction boxes for wiring connections
• Protecting cable splices and terminations
• Surface-mounted installations in residential, commercial, and industrial settings
• Outdoor applications where IP54 protection is required

Key specifications

• Brand: MITON
• Model: MT-P1280
• MPN: MT-P1280
• EAN: 5908231259516
• Category: Mounting & Enclosure Box
• Product Colour: Grey
• Mounting Type: Surface-mounted
• Ingress Protection: IP54
• Material: Polypropylene (PP)
• Colour: Grey (RAL 7035)
• External Dimensions: 128 x 80 x 50 mm (L x W x H)
• Number of Cable Entries: 8
• Cable Entry Type: Flexible membrane glands
• Lid Fastening: Screw-on
• Operating Temperature: -25°C to +60°C
• Glow-Wire Test: 650°C
• Halogen-Free: Yes
• Impact Resistance: IK07
• Rated Insulation Voltage: 400 V
• Standards: EN 60670-1, EN 60529, CE
• Internal Mounting: No pre-drilled mounting points (empty box)

Recommendations

For optimal installation, ensure the mounting surface is clean and dry. Use appropriate cable glands for the cable diameter. The box is empty inside, allowing flexible internal mounting of terminals or connectors. Suitable for use with cables up to the capacity of the membrane entries.
