Módulo de alimentação integrado Bachmann KAPSA S 2xUTE 1xCM 0,2m

The Bachmann KAPSA S 2xUTE 1xCM 0.2m is a compact integrated power module designed for flush mounting in desks, conference tables, and kitchen worktops. It features two Schuko outlets (Type F) and one empty module slot for customisation, with a short 0.2 m input cable terminated with a GST18i3 male connector. This retractable, modular unit offers a sleek silver cover and black body, ideal for modern office and furniture integration.

Advantages

Space-saving retractable design keeps outlets hidden when not in use. Modular slot allows addition of USB chargers, data ports, or other modules. Easy flush-mount installation with standard cut-out dimensions. High-quality construction ensures reliable power distribution up to 16A.

Suitable for

• Office desks and workstations
• Conference rooms and meeting tables
• Kitchen islands and countertops
• Furniture integration in commercial and residential spaces

Key specifications

• Product type: Integrated power module / desktop power strip
• Number of power outlets: 2 (Schuko Type F)
• Custom module slots: 1 (empty, for user-supplied module)
• Input cable length: 0.2 m
• Input connector: GST18i3 (male)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Mounting type: Flush mount / desktop integration
• Cut-out dimensions (W x D): 189 x 120 mm
• Installation depth: 48 mm
• Housing material: Plastic / metal
• Colour: Silver (cover), black (body)
• Protection class: IP20

Recommendations

For optimal functionality, pair with a compatible module (e.g., USB charger, HDMI, or data port) to fill the empty slot. Ensure cut-out dimensions match your furniture before installation. Professional installation recommended for flush-mount applications.
