Módulo de comutação Busch-Jaeger 83320/2 — 2 saídas, 36×65×90 mm

Busch-Jaeger 83320/2 is a compact switch module with two outputs, designed for integration into electrical control panels and distribution boxes. With a width of 36 mm, depth of 65 mm and height of 90 mm, the module provides a space-efficient solution for switching and controlling circuits in residential and light commercial electrical installations. The unit is produced by busch jaeger and is intended for fixed installation within standard enclosures or mounting frames.

Advantages

The module offers two independent outputs in a narrow housing that saves space in distribution boards. Its standard dimensions and robust construction support straightforward mounting in a variety of enclosures. The design simplifies wiring and circuit segregation, enabling clear separation of control paths while maintaining a small footprint.

Suitable for

Key specifications

How to use

Install the switch module into a compatible control panel or distribution box following applicable local electrical codes. Secure the module in the intended mounting location, connect the incoming supply and outgoing circuit conductors to the appropriate terminals, and ensure all wiring is tightened and insulated according to installation standards. Verify correct operation by testing each output under no-load and then under normal load conditions. Installation and commissioning should be performed by a qualified electrician.

Recommendations

Use this switch module in dry, ventilated enclosures and ensure that operating temperatures of the installation remain within the recommended range for electrical components. For safety and longevity, follow manufacturer installation instructions, protect the module with suitable overcurrent devices, and perform periodic inspections of terminal connections.
