Módulo de tomada de antena Busch-Jaeger 0232-102, tomada de derivação 3 saídas, encastrar 2CKA000230A1550

For electricians and installers setting up a home TV, radio, and satellite distribution network, the Busch-Jaeger 0232-102 antenna socket insert provides three separate connections in a single flush-mounted unit. It is a terminal socket (Stichdose) for star distribution networks, delivering TV, FM radio, and data/SAT signals to individual outlets.

Key specifications

• Socket type: Terminal socket (Stichdose)
• Number of outputs: 3
• Output 1 (TV): IEC male connector, 47–862 MHz
• Output 2 (Radio): IEC female connector, 87.5–108 MHz
• Output 3 (Data/SAT): F-connector female, 5–2400 MHz
• Connection attenuation: 4 dB for TV and radio, 4 dB for data/SAT (950–2400 MHz)
• Return path capability: Yes (5–68 MHz)
• Shielding class: Class A (EN 50083-2)
• Mounting type: Flush-mounted (Unterputz)
• Material: Plastic
• Compatibility: Busch-Jaeger central plates for antenna sockets

Why choose it

This insert combines three services in one compact unit, reducing wall clutter and simplifying installation. Its Class A shielding ensures excellent signal isolation, and the return path support makes it suitable for interactive services like cable internet or pay-TV. The use of standard connectors (IEC and F-type) allows direct connection of common coaxial cables.

Ideal use cases

• Star distribution networks in residential buildings
• Terminal points in loop-through systems
• Connecting TV, FM radio, and satellite receivers at a single wall outlet
• Retrofit installations where a flush-mounted socket is required

Good to know

The socket is designed for use with Busch-Jaeger central plates, ensuring a consistent look with the rest of the electrical installation. It is not suitable for use as a pass-through socket; for loop-through applications, a different model is required.
