JOINT RSS-60-100 PG conector de cabo inline, 60-100 mm², IP68 preenchido com gel

Inline cable joint for low voltage power distribution, offering a permanent, tool-free seal for conductors from 60 to 100 mm². Its pre-filled gel technology delivers IP68 protection immediately upon installation, making it ideal for direct burial and submerged environments without the need for heat or special tools.

Advantages

Cold application eliminates the need for torches or heat guns, saving time and reducing risk. The pre-filled gel ensures a void-free seal around each conductor, even with irregular cable shapes. Re-enterable design allows for future maintenance or circuit modifications. Impact-resistant polypropylene housing withstands mechanical stress, while UV resistance and halogen-free, flame-retardant materials ensure long-term durability in harsh environments.

Suitable for

• Low voltage power distribution networks up to 1 kV
• Underground cable connections requiring direct burial capability
• Submerged or wet location installations (IP68)
• Industrial, commercial, and infrastructure projects
• Repair and extension of 1-5 core cables with outer diameter 18-35 mm

Key specifications

• Conductor cross-section: 60-100 mm²
• Voltage rating: up to 1 kV
• Number of cores: 1-5 (universal)
• Sealing method: pre-filled gel, cold application
• Environmental protection: IP68
• Operating temperature: -20°C to +90°C
• Housing material: impact-resistant polypropylene
• UV resistant, halogen-free, flame retardant
• Direct burial and submersible
• Re-enterable
• Standards: EN 50393
• Cable outer diameter range: 18-35 mm

Recommendations

For reliable, maintenance-friendly low voltage cable connections, choose the JOINT RSS-60-100 PG. Its robust construction and easy installation make it a dependable choice for any project requiring long-term performance in demanding conditions.
