OBO Bettermann GES9 55U Módulo vertical para montagem em calha (7405039)

In underfloor and duct installation systems, accommodating power and data outlets cleanly can be a challenge. The OBO Bettermann GES9 55U Vertical Device Insert solves this by providing a stable, pre-sized mounting frame for standard 55x55 mm modules within GES9 floor boxes and duct systems.

Who is it for

Electricians and installers working with OBO Bettermann GES9 underfloor or duct systems who need a reliable, halogen-free insert to mount power sockets, data outlets, or other 55x55 mm devices in a vertical orientation.

Main features

• Vertical mounting orientation for duct installations
• Compatible with OBO Bettermann GES9 floor boxes and duct systems
• Accommodates three 55x55 mm modules or six 22.5x45 mm modules
• Made from halogen-free, flame-retardant polyamide (PA)
• Cream white (RAL 9001) finish
• Empty insert for custom device installation

Specifications

• Product Type: Device Insert
• Mounting Orientation: Vertical
• System Compatibility: OBO Bettermann GES9 Floor Boxes / Duct Systems
• Module Size: 55U (55x55 mm standard)
• Number of Modules: 3 (for 3x 55x55 mm devices or 6x 22.5x45 mm devices)
• Colour: Cream White (RAL 9001)
• Material: Polyamide (PA)
• Halogen-free: Yes
• Flame Retardant: Yes, self-extinguishing
• Protection Class (IP): IP20 (when installed in suitable system)
• Application: Underfloor systems, Floor boxes, Duct systems
• Installation Type: Duct Mounting
• Series: GES9
• Pre-wired: No (empty insert for custom device installation)

Tips

Ensure the insert is correctly aligned with the duct profile before securing. For combined power and data installations, plan module placement to maintain required separation distances.
