OBO PLM SIC 0810 FS conector para calha de cabos PLM-D 0810

Strip-galvanised steel splice connector engineered for OBO Bettermann PLM-D cable ladders with 80 mm side height, supporting widths from 100 mm to 600 mm.

Overview

The OBO PLM SIC 0810 FS is a dedicated splice connector for joining sections of the OBO Bettermann PLM-D cable ladder system. Manufactured from strip-galvanised steel, it provides reliable mechanical continuity and long-term corrosion protection in indoor and dry outdoor environments. The connector is designed for screw-on installation, with fasteners ordered separately to suit the specific ladder width and load requirements.

What stands out

• Compatible with PLM-D cable ladders with 80 mm side height and widths from 100 mm to 600 mm.
• Strip-galvanised steel construction ensures robust corrosion resistance.
• Compact 100 mm length with 30 mm width and 2 mm thickness for easy handling.
• Simple screw-on mounting method allows quick assembly on site.
• Sold individually, enabling precise quantity planning for each project.

Technical details

• Product type: Splice connector
• Application: Joining cable ladder sections
• Compatible cable ladder series: OBO Bettermann PLM-D
• Compatible side height: 80 mm
• Material: Steel
• Surface treatment: Strip galvanised (Bandverzinkt)
• Corrosion protection: Yes
• Mounting method: Screw-on (fasteners sold separately)
• Connector dimensions (L x W x T): 100 mm x 30 mm x 2 mm
• Colour: Metallic
• Environmental suitability: Indoor / dry outdoor
• Manufacturer series designation: PLM SIC

Our verdict

A reliable, corrosion-resistant splice connector that ensures secure joining of PLM-D cable ladder sections, ideal for professional installations.
