Painel de E/S Supermicro MCP-260-00042-3N cinzento compatível com placas-mãe de servidor X13

The Supermicro MCP-260-00042-3N grey I/O shield is designed for X13 server motherboards to provide an exact rear-panel fit, protect internal components from dust and electromagnetic interference, and maintain secure alignment of ports with the chassis cutouts. The shield helps ensure reliable connections for network, USB, video and other rear I/O interfaces while supporting airflow management within rack and tower server enclosures.

Advantages

This I/O shield offers a precise fit for X13 server motherboards in order to prevent misalignment of connectors and to reduce the risk of bent pins or loose ports. The metal construction provides basic EMI shielding and mechanical protection for ports at the rear of the system. The grey finish is neutral and suitable for most server chassis, while the design supports standard cutouts for easy installation without modification.

Suitable for

• Server builds using X13 generation motherboards where a compatible rear I/O shield is required
• Rackmount or tower servers that need improved port alignment and rear-panel protection
• System maintenance or repairs that involve replacing a damaged or missing I/O shield
• Environments where basic EMI reduction and dust ingress control at the rear panel are desired

Key specifications

• Form factor: Standard rear I/O shield designed for X13 server motherboard layout
• Material: Metal construction for mechanical protection and EMI attenuation
• Color: Grey finish compatible with common server chassis
• Compatibility: Matches rear I/O port arrangement of X13 server motherboards
• Mounting: Snap-in design for tool-free installation into compatible chassis cutouts

How to use

Turn off and unplug the server before installing the I/O shield. From inside the chassis, align the shield with the motherboard rear I/O area and press it into the chassis cutout until it snaps into place and the ports align with their openings. Once the I/O shield is secured, install the motherboard and verify that each rear connector passes cleanly through its corresponding opening. If removal is required, gently pry the shield out from the chassis while supporting adjacent connectors to avoid damage.

Recommendations

Install this I/O shield specifically in systems built with X13 server motherboards and verify port alignment before final assembly. Avoid bending the shield during installation and confirm chassis compatibility with standard rear I/O cutouts to ensure a secure fit and proper port access.
