Painel LCD Fujitsu LM238WF2-SSM1-23,8" (CP789800-02)

When a desktop monitor, all-in-one PC, or industrial display needs a reliable 23.8-inch panel, technicians and system builders turn to the Fujitsu CP789800-02. This LG Display LM238WF2-SSM1 module delivers crisp Full HD visuals with wide viewing angles, making it a direct replacement for broken screens or a solid choice for custom display projects.

Key specifications

• 23.8-inch IPS panel with 1920 x 1080 (Full HD) resolution
• WLED backlight, 250 cd/m² typical brightness, 1000:1 contrast ratio
• 14 ms (GtG) response time, 60 Hz refresh rate, 178°/178° viewing angles
• 8-bit colour depth (16.7 million colours), anti-glare hard coating (3H)
• 30-pin eDP interface for direct connection to compatible boards
• Manufactured by LG Display, model LM238WF2-SSM1

Why choose it

The IPS technology ensures accurate colours and consistent brightness from almost any angle, while the anti-glare surface reduces reflections in bright environments. Its eDP connector simplifies integration into modern systems, and the panel's standard dimensions and mounting holes fit many 23.8-inch monitor chassis.

Ideal use cases

• Replacing a faulty screen in a desktop monitor or all-in-one PC
• Building a custom monitor or kiosk display
• Upgrading industrial equipment with a high-quality Full HD panel
• Repairing point-of-sale terminals or medical displays

Good to know

This panel is sold as a bare component without a driver board, cables, or mounting brackets. It requires a compatible eDP signal source and appropriate power supply. Always verify the exact panel model and connector orientation before purchase to ensure compatibility with your device.
