Passa-cabos de mesa VivoLink VLDG24L-B, preto, grande, até 55 mm

This desk grommet requires a 24mm hole in the desk. The large version fits desk plates up to 55mm thick and is designed so Vivolink HDMI, DisplayPort, USB-C or RJ45 cable heads can be led through the desk without cutting the cable. The grommet is made of black oxidated aluminium for a durable, low-profile finish.

Advantages

The Vivolink 24mm desk grommet allows neat cable routing through a small circular opening while accommodating full-size cable connectors. Its 55mm compatible depth makes it suitable for thicker desks. The black oxidated aluminium construction provides corrosion resistance and a professional appearance.

Suitable for

• Routing HDMI cables with connector heads through a desk
• Routing DisplayPort and USB-C cables without removing connector housings
• Passing RJ45 (Ethernet) connectors through a desktop
• Use in home offices, meeting rooms, and workstations with desks up to 55mm thick

Key specifications

• Required desk hole diameter: 24 mm
• Compatible desk thickness: up to 55 mm
• Material: black oxidated aluminium
• Compatible cable types: HDMI, DisplayPort, USB-C, RJ45

How to use

Drill or prepare a 24mm diameter hole in the desk at the desired cable entry point. Insert the grommet into the hole so it sits flush with the desk surface. Feed cables through the grommet individually; the opening is sized to allow connector heads to pass through without removing them. Ensure cables are routed without sharp bends to avoid stress on the connectors.

Recommendations

For best results, verify your desk thickness is 55mm or less before installation and use appropriate tools to create a clean 24mm hole. Periodically check the grommet and cables for wear and reposition cables if signs of chafing appear.
