Passagem de cabo Eaton KT4 para cabo 14-68 mm, EPDM, preto, IP65, isento de halogéneos 036269

IP65-rated protection meets a wide 14–68 mm clamping range in the Eaton KT4 cable grommet. Engineered from UV-resistant, halogen-free EPDM, it seals enclosures, control cabinets, and machinery against dust, moisture, and temperature extremes from -40°C to +120°C.

Overview

The Eaton KT4 (MPN 036269) is a push-in cable grommet designed for reliable cable entry in industrial and commercial installations. Its flexible EPDM body accommodates cables with diameters from 14 mm to 68 mm, providing a snug, strain-relieving fit without the need for additional fasteners. The black grommet snaps into a 75 mm mounting hole and offers an outer diameter of 85 mm, making it suitable for standard enclosure knockouts.

What stands out

• IP65 ingress protection keeps dust and low-pressure water jets out of your enclosure.
• Halogen-free EPDM material is safe for use in public buildings and sensitive environments.
• Wide operating temperature range from -40°C to +120°C suits harsh industrial conditions.
• UV and flame retardant properties ensure long-term durability and safety.
• Tool-free push-in installation saves time during assembly and maintenance.

Technical details

• Cable diameter range: 14–68 mm
• Material: EPDM (Ethylene Propylene Diene Monomer)
• Colour: Black
• Protection class: IP65
• Mounting type: Push-in / snap-in
• Mounting hole diameter: 75 mm
• Outer diameter: 85 mm
• Number of cable entries: 1
• Series: KT
• RoHS compliant: Yes
• Halogen-free: Yes
• UV resistant: Yes
• Flame retardant: Yes
• Operating temperature range: -40°C to +120°C
• Application: Cable entry for enclosures, control cabinets, and machinery
• Manufacturer: Eaton Electric GmbH

Our verdict

The Eaton KT4 delivers robust, certified cable entry with a generous clamping range and all-weather resilience. Its halogen-free, UV-stable EPDM construction and IP65 rating make it a dependable choice for demanding electrical installations.
