Placa de identificação EATON M22S-ST-D7 'I' preto/branco para série M22 216488

On industrial control panels, operators need clear, durable labeling for pushbuttons and selector switches. The EATON M22S-ST-D7 legend plate provides a pre-printed 'I' symbol (ON/START) on a black background with white inscription, ensuring quick recognition in demanding environments. Designed for the Eaton M22 series, it snaps onto the front of compatible control devices without tools.

Key specifications

• Product type: Legend plate / labeling element
• Compatibility: Eaton M22 series control devices
• Inscription: 'I' (ON / START symbol)
• Inscription colour: White
• Background colour: Black
• Material: High-quality plastic
• Mounting type: Front mounting, snap-on
• Shape: Square
• Visible dimensions (L x W): 29.7 x 29.7 mm
• Text orientation: Horizontal
• Number of inscriptions: 1
• Environmental protection: IP66 (when correctly mounted on compatible device)
• Resistance: UV-resistant, chemical-resistant
• Operating temperature range: -25 to +70 °C
• Storage temperature range: -40 to +80 °C
• Standards compliance: IEC/EN 60947
• Design: Flat, flush mounting

Why choose it

The legend plate offers a simple way to label control elements with a universally understood symbol. Its snap-on design reduces installation time, and the durable plastic withstands harsh industrial conditions, including UV exposure and chemicals. The high contrast between white and black ensures legibility even in low-light or high-glare settings.

Ideal use cases

• Labeling start buttons on motor control panels
• Identifying ON positions for selector switches
• Replacing worn or illegible labels on existing M22 devices
• Standardizing control panel labeling across a facility

Good to know

The plate is specifically designed for the Eaton M22 series and may not fit other series. The IP66 rating applies only when mounted on a compatible device with appropriate sealing. The inscription is printed, not engraved, but the material is resistant to fading and abrasion.
