Placa de rede Ethernet BlueOptics baseada em E810-CAM2 100G dual-port QSFP28 (E810CAM2-2CP-BO)

The BlueOptics E810-CAM2-based Ethernet Network Card 100G Dual-Port QSFP28 (E810CAM2-2CP-BO) is a high-performance network adapter designed for demanding data center, cloud computing, and enterprise server environments. Powered by the Intel E810-CAM2 controller, this PCI Express 4.0 x16 card delivers aggregate data transfer rates of up to 200 Gbps, providing exceptional throughput for bandwidth-intensive applications.

Advantages

With dual QSFP28 ports supporting 100 Gigabit Ethernet, this network card offers superior scalability and flexibility. Advanced features such as SR-IOV, VMDq, and RDMA over Converged Ethernet (RoCE v2) enhance virtualization performance and reduce CPU overhead. The card supports a wide range of networking standards and offload capabilities, ensuring efficient data processing and low latency.

Suitable for

• Data centers requiring high-speed connectivity
• Cloud computing and HPC environments
• Enterprise servers and network virtualization
• Applications demanding low latency and high throughput

Key specifications

• Controller Chipset: Intel E810-CAM2
• Network Interface: 100 Gigabit Ethernet
• Port Configuration: Dual-port (2 ports)
• Connector Type: 2 x QSFP28
• Bus Interface: PCI Express 4.0 x16
• Form Factor: PCIe Low Profile / Full Height (bracket included)
• Aggregate Data Transfer Rate: 200 Gbps
• Supported Standards: IEEE 802.3ae, 802.3ba, 802.3cd, 802.1Q, 802.1p, 802.1ad, 802.3az
• Virtualization Features: SR-IOV, VMDq, VT-c
• Offload Capabilities: TCP/UDP/IP Checksum Offload, TSO, LRO, RSS, FCoE, iSCSI
• RDMA Support: RoCE v2
• Management Features: PXE, SNMP, NC-SI, IPMI pass-through
• Operating System Support: Windows Server, Linux, VMware ESXi, FreeBSD
• Jumbo Frame Support: Up to 9.5 KB
• Flow Control: IEEE 802.3x
• LED Indicators: Link/Activity/Speed per port
• Operating Temperature: 0°C to 55°C
• Humidity Range: 5% to 95% non-condensing

Recommendations

For optimal performance, pair this network card with compatible QSFP28 transceivers and cables. Ensure your system has a PCIe 4.0 x16 slot available. This adapter is ideal for building high-speed, low-latency networks in virtualized and cloud environments.
