PowerWalker Caixa de Filtro Para ICR IoT DNV

The PowerWalker Filter Box For ICR IoT DNV is a robust surge protection and EMI/RFI filtering device designed to safeguard sensitive IoT equipment, IP cameras, industrial networks, and vehicle systems. It combines DC power line and Ethernet data line protection in a compact metal housing, ensuring reliable operation in harsh environments.

Advantages

This filter box provides comprehensive protection against voltage surges and electromagnetic interference, extending the lifespan of connected devices. Its wide input voltage range and Gigabit Ethernet compatibility make it versatile for various applications. The unit supports PoE/PoE+ and can be wall-mounted or DIN-rail mounted for flexible installation.

Suitable for

• IoT devices and gateways
• IP cameras and surveillance systems
• Industrial automation networks
• Vehicle electronics and telematics

Key specifications

• Protection Type: Surge Protection (SPD), EMI/RFI Filtering
• Protected Lines: DC Power Line, Ethernet Data Line
• DC Input Voltage: 9 - 36V DC
• DC Output Voltage: 9 - 36V DC
• Max DC Current: 5A
• Ethernet Speed: 10/100/1000 Mbps (Gigabit Ethernet)
• PoE Support: Yes (PoE/PoE+ compatible)
• DC Surge Current (Max): 10kA (8/20µs)
• Data Surge Current (Max): 10kA (8/20µs)
• DC Connectors: Screw Terminals (Input/Output)
• Ethernet Connectors: RJ45 (Input/Output)
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 0 - 95% (non-condensing)
• Housing Material: Metal (Aluminum)
• Mounting Options: Wall-mount, DIN-rail mountable
• Certifications: CE, RoHS

Recommendations

For optimal protection, install the filter box close to the equipment being protected. Ensure proper grounding according to local electrical codes. This device is ideal for use in industrial environments where power quality and data integrity are critical.
