PULSAR AWZ579 Módulo de fusíveis 16 canais 1A fusíveis de vidro

The PULSAR AWZ579 is a 16-channel fuse module designed for reliable overcurrent protection in CCTV, access control, and alarm systems. It accepts 10-30V DC input and distributes the same voltage to each channel, with each channel protected by a 5x20mm glass fuse rated at 1A (F1A). The module features LED indicators for each channel to show fuse status, making troubleshooting quick and easy. Housed in a durable ABS plastic enclosure, it supports surface mounting and screw terminal connections for secure wiring.

Advantages

• 16 individually fused channels with visual LED status indicators
• Wide input voltage range (10-30V DC) for versatile use
• Short-circuit and overload protection per channel
• Compact surface-mount design saves space
• Screw terminals for reliable, tool-free connections

Suitable for

• CCTV systems requiring distributed power protection
• Access control systems with multiple locks or readers
• Alarm and security panels needing per-channel fusing
• Any low-voltage DC application needing organized fuse distribution

Key specifications

• Number of Channels: 16
• Input Voltage: 10-30V DC
• Output Voltage: Same as Input
• Fuse Type: Glass Fuses 5x20mm
• Fuse Rating per Channel: 1A (F1A)
• Total Current Capacity: 16A max.
• Protection: Short-Circuit (SCP), Overload (OLP)
• Indication: 16x LED (fuse status)
• Terminals: Screw Terminals
• Mounting: Surface Mount
• Housing Material: ABS Plastic
• Operating Temperature: -10°C to +40°C
• Relative Humidity: 20% to 90% (non-condensing)

Recommendations

For optimal performance, use only 5x20mm glass fuses rated at 1A. Ensure total load across all channels does not exceed 16A. Suitable for indoor use only.
