RUKO ENR-RU-15,0mm placa terminal e intermédia para bornes de calha WAGO TOPJOB S

Terminal block assemblies often lack a clean, insulated finish at the open end, leaving live parts exposed and the assembly vulnerable to contamination. The RUKO GMBH ENR-RU-15.0mm end and intermediate plate solves this by providing a secure, insulating cover that snaps directly onto WAGO TOPJOB S 2-conductor terminal blocks, ensuring safe and tidy installations.

Who is it for

Electrical panel builders, industrial maintenance technicians, and automation engineers who work with WAGO TOPJOB S terminal blocks and need reliable end covers to complete their DIN-rail assemblies.

Main features

• Compatible with WAGO TOPJOB S 2-conductor terminal blocks
• Snap-on mounting for quick and secure installation
• Made from polyamide 66 (PA 66) with UL 94 V-0 flammability rating
• Gray colour for clear visual separation
• Provides insulation and protects against accidental contact

Specifications

• Product type: End and intermediate plate
• Series: TOPJOB S
• Material: Polyamide 66 (PA 66)
• Color: Gray
• Flammability rating: UL 94 V-0
• Operating temperature: -35 °C to +105 °C
• Storage temperature: -35 °C to +105 °C
• Rated voltage: 800 V
• Pollution degree: 3
• Mounting type: Snap-on
• Compatible rail types: DIN-rail 35 x 15 mm, DIN-rail 35 x 7.5 mm

Tips

Always install an end plate at the open end of a terminal block group to maintain insulation and prevent accidental contact. For intermediate separation, use additional plates between groups of different potentials.
