Rutenbeck 2600270 Cat.6A ficha RJ45 de montagem em campo, blindada, sem ferramentas, pack de 10

Supports 10 Gigabit Ethernet with 500 MHz bandwidth in a tool-free, shielded RJ45 plug for solid or stranded conductors.

Overview

The Rutenbeck 2600270 is a Cat.6A RJ45 plug designed for field termination without special tools. Its zinc die-cast housing provides full shielding, and gold-plated contacts ensure reliable signal integrity for high-speed networks.

What stands out

• Tool-free assembly for quick on-site installation
• Shielded zinc die-cast housing for EMI protection
• Supports PoE up to IEEE 802.3bt (PoE++)
• Accepts solid and stranded conductors from AWG 22 to 26
• Pack of 10 pieces

Technical details

• Connector type: RJ45 plug, 8P8C
• Category: Cat.6A
• Shielding: Shielded (STP/FTP)
• Data rate: 10 Gbit/s
• Frequency: 500 MHz
• Conductor compatibility: solid and stranded, AWG 22/1 - 26/1 and AWG 22/7 - 26/7
• Cable diameter range: 6.0 - 9.0 mm
• Contact plating: gold, 50µ"
• Operating temperature: -40°C to +70°C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Our verdict

A robust, tool-free Cat.6A connector for professionals needing reliable 10G performance in the field.
