Rutenbeck Cabo de extensão FTTH LC/APC OS2 20 m 228051720

FTTH extension cable with LC/APC connectors on both ends, pre-assembled with a 20 m single-mode OS2 fiber. The low-smoke zero-halogen jacket and 3 mm diameter make it suitable for indoor fiber-to-the-home and fiber-to-the-building installations.

Advantages

LC/APC connectors provide low insertion loss and high return loss, ensuring reliable signal transmission. The LSZH jacket reduces toxic smoke and corrosive gases in case of fire.

Suitable for

• FTTH (Fiber To The Home)
• FTTB (Fiber To The Building)
• Indoor fiber optic extensions

Key specifications

• Cable length: 20 m
• Fiber type: OS2 single-mode
• Connectors: LC/APC to LC/APC
• Jacket material: LSZH
• Jacket colour: Yellow
• Cable diameter: 3 mm
• Insertion loss: ≤ 0.3 dB
• Return loss: ≥ 60 dB

Recommendations

For FTTH extensions requiring a pre-terminated, ready-to-install cable with APC polished connectors.
