Schroff Pentair 3U 4HP painel frontal de alumínio 30807-776

For engineers building modular Eurocard systems, the Schroff 30807-776 front panel delivers a precise 3U × 4HP aluminium blank that fits standard subracks without the bulk of pre-drilled alternatives. Its natural anodized finish resists fingerprints and light corrosion, while the 2.5 mm thickness keeps the panel rigid enough for repeated module swaps.

Highlights

• Standard 3U height and 4HP width per IEC 60297-3-101
• Aluminium body with natural anodized silver surface
• 2.5 mm material thickness for stable mounting
• RoHS compliant passive component
• Compatible with Schroff subracks and 19-inch rack systems

In daily use

Mount the panel directly into a Eurocard subrack to close unused slots or serve as a base for custom connectors. Because no mounting screws are included, you can select the exact hardware for your enclosure's thread type. The silver finish blends with most rack interiors and wipes clean with a dry cloth.

Full specifications

• Brand: Schroff
• Model: 30807-776
• MPN: 30807776
• EAN: 4036088055928
• Product type: Front panel
• Panel height: 3U
• Panel width: 4HP
• Material: Aluminium
• Finish: Natural anodized
• Colour: Silver
• Thickness: 2.5 mm
• Standard: IEC 60297-3-101 (Eurocard)
• Mounting type: Screw-on (screws not included)
• Application: Enclosure component, module mounting, gap filling
• RoHS compliant: Yes
• Operating temperature range: -40 °C to +85 °C (passive component)
• Protection class: IP20 (when installed in a suitable enclosure)

Final note

A straightforward aluminium blank that keeps your Schroff subrack tidy and ready for future expansion—order the matching screws separately for a complete installation.
