SIEMENS SENTRON 5SL6 disjuntor 230V 6kA 1P+N B13 (5SL6013-6)

Miniature circuit breaker with 1 protected pole and switched neutral, rated for 13 A and 230 V AC. The B tripping characteristic ensures reliable protection of circuits with moderate inrush currents, while the 6 kA breaking capacity handles short-circuit faults safely. Compact 2-module width saves space on the DIN rail.

Advantages

Precise overload and short-circuit protection for residential and commercial installations. Screw terminals accommodate conductors up to 35 mm² solid or 25 mm² stranded, simplifying wiring. Mechanical endurance of 20,000 switching cycles ensures long service life.

Suitable for

• Protection of socket outlets and lighting circuits in residential buildings
• Control circuits in industrial panels
• Distribution boards where space is limited

Key specifications

• Tripping characteristic: B
• Rated current: 13 A
• Rated voltage: 230 V AC
• Breaking capacity: 6 kA
• Poles: 1P+N
• Mounting: DIN rail
• Width: 2 modules (36 mm)
• Terminals: screw, 0.75–35 mm² solid / 0.75–25 mm² stranded
• Operating temperature: -25 to +45 °C
• Electrical endurance: 10,000 cycles
• Mechanical endurance: 20,000 cycles

Recommendations

For reliable protection of 13 A circuits, pair with a suitable residual current device if additional earth leakage protection is required.
