Siemens SINAMICS G110 Variador de Frequência 6SL5510-1BE17-0AF0, 0,75 kW, Monofásico 200-240V, IP20

Industrial machines often need a compact, reliable way to control three-phase motors from a single-phase supply. The Siemens SINAMICS G110 frequency converter solves this by converting a standard 200-240V single-phase input into a variable-frequency three-phase output, enabling precise speed control for pumps, fans, conveyors, and similar equipment.

Who is it for

This drive is built for machine builders, panel builders, and maintenance engineers who require a simple, cost-effective solution for basic motor control tasks. It is particularly suited to applications where space is limited and wall mounting is preferred.

Main features

• Rated output power: 0.75 kW (1 HP) with a rated output current of 4.1 A
• Single-phase 200-240V input, three-phase 0-240V output
• Output frequency range: 0-650 Hz for flexible speed control
• V/f control method for straightforward operation
• Integrated Class A filter for reduced electromagnetic interference
• USS protocol via RS485 for communication
• 3 digital inputs, 1 analog input (0-10V), and 1 relay output
• DC braking and compound braking functions
• Fan-cooled with IP20 protection, suitable for control cabinet installation

Specifications

• Input voltage: 1-phase AC 200-240V (+10%/-10%)
• Input frequency: 50/60 Hz
• Output voltage: 3-phase AC 0-240V
• Rated output current: 4.1 A
• Control method: V/f control
• Communication: USS protocol via RS485
• Digital inputs: 3 (freely programmable)
• Analog inputs: 1 (0-10V)
• Digital outputs: 1 (relay)
• Cooling method: Fan-cooled
• Ambient operating temperature: -10 to +40 °C (without derating)
• Mounting type: Wall mounting
• Protection class: IP20

Tips

Ensure adequate ventilation around the drive, as it is fan-cooled. For operation above 40°C, derating may be required. The integrated Class A filter is suitable for industrial environments; for residential areas, additional filtering may be needed.
