Sistema de suporte Barkan 3400L 70 polegadas preto peso máximo 40 kg

The Barkan 3400L mounting system is designed for flat-panel screens with diagonal sizes from 40" to 70" and a maximum supported weight of 40 kg. It provides adjustable tilt from 0° to 10°, rotation up to 90°, and a wide range of wall-to-screen distance that can be set between 6 cm and 63.9 cm. The bracket accommodates VESA mounting patterns from 200 x 100 mm up to 600 x 400 mm, enabling compatibility with a broad selection of TVs and monitors while allowing flexible positioning for viewing and installation needs.

Advantages

The mounting assembly combines low-profile and extendable positioning thanks to its adjustable distance from the wall, allowing both a compact fit and extended placement when required. Tilt and rotation adjustments facilitate precise alignment and improved viewing angles without the need to reposition the entire display. The broad VESA compatibility and a 40 kg weight capacity ensure the mount works with many mid-to-large size screens, while the construction supports stable, long-term use in residential and commercial environments.

Suitable for

• Living rooms and home theaters where adjustable viewing angle is needed
• Conference rooms and offices for wall-mounted displays
• Retail and public areas requiring secure, visible screens
• Rooms with limited space that benefit from compact or extended mounting

Key specifications

• Screen size compatibility: 40"–70"
• Maximum supported weight: 40 kg
• Tilt range: 0° to 10°
• Rotation range: up to 90°
• VESA compatibility: from 200 x 100 mm to 600 x 400 mm
• Adjustable distance from wall: 6 cm to 63.9 cm

How to use

Attach the mount to a suitable wall surface following the included installation instructions and using appropriate fasteners for the wall material. Secure the screen to the mounting brackets matching the VESA pattern of the display, then tighten all fasteners to the specified torque. Adjust the distance from the wall, set the tilt within the 0°–10° range, and rotate the display up to 90° to achieve the desired viewing position. Verify that the display is level and that all connections are secure before regular use.

Recommendations

For safe and reliable installation, use appropriate wall anchors or fixings rated for the combined weight of the mount and screen. Check the VESA pattern and weight of the display before installation and confirm the wall structure can support the load. Periodically inspect mounting fasteners and joints for tightness and signs of wear.
