Supermicro FAN-0217L4 ventoinha 80x80x38mm 16500 RPM PWM

The Supermicro FAN-0217L4 is a high-performance axial fan designed for server and workstation cooling. With its 80x80x38mm form factor and dual ball bearing construction, it delivers exceptional airflow and reliability for demanding environments.

Advantages

This fan features a 4-pin PWM connector for precise speed control, ensuring optimal cooling while minimizing noise. Rated at 16500 RPM, it provides 130 CFM of airflow and 52 mmH2O static pressure, making it ideal for high-density systems. The dual ball bearing design offers a life expectancy of 70,000 hours at 40°C, ensuring long-term durability.

Suitable for

• Supermicro server and workstation systems requiring 80mm fan replacement or upgrade
• General chassis cooling in high-performance computing environments
• Applications demanding high airflow and static pressure

Key specifications

• Fan Type: Axial Fan
• Dimensions: 80 x 80 x 38 mm
• Rotational Speed: 16500 RPM
• Airflow: 130.0 CFM
• Static Pressure: 52.0 mmH2O
• Noise Level: 65.0 dBA
• Rated Voltage: 12V DC
• Rated Current: 1.50 A
• Power Consumption: 18.0 W
• Bearing Type: Dual Ball Bearing
• Connector Type: 4-pin PWM
• Life Expectancy: 70,000 hours at 40°C
• Features: PWM Speed Control

Recommendations

For optimal performance, ensure compatibility with your Supermicro system. This fan is a direct replacement for the FAN-0217L4 model and is suitable for use in various Supermicro chassis.
