Suporte de abraçadeira HellermannTyton H9P PA66HS BK 100, preto, orifício de 4,2 mm, parafuso M4, PA66 termoestabilizado, 100 unid.

Cable tie mount with screw fixing for secure cable routing. Heat-stabilised polyamide 6.6 body withstands temperatures from -40 °C to +105 °C, making it suitable for demanding environments. The 4.2 mm fixing hole accepts M4 screws, providing a reliable anchor point for cable ties up to 4.8 mm wide.

Advantages

The heat-stabilised PA66 material maintains mechanical strength across a wide temperature range. The compact 16 mm length and 11 mm width allow installation in tight spaces. Halogen-free construction reduces toxic smoke emissions in case of fire.

Suitable for

• Securing cable ties to panels, walls, or chassis
• Automotive, industrial, and electrical installations
• Applications requiring UL94 V2 flammability rating

Key specifications

• Material: Polyamide 6.6, heat stabilised (PA66HS)
• Colour: Black
• Fixing hole diameter: 4.2 mm
• Recommended screw size: M4
• Max cable tie width: 4.8 mm
• Dimensions: 16 mm (L) x 11 mm (W) x 6.5 mm (H)
• Operating temperature: -40 °C to +105 °C
• Flammability: UL94 V2
• Halogen-free: Yes
• Pack quantity: 100 pieces

Recommendations

Use with M4 screws and cable ties up to 4.8 mm wide. Ensure mounting surface is clean and flat for optimal adhesion.
