Terminal de entrada de alimentação MIBOXER S1 para sistemas LED SYS Series X

The MIBOXER S1 Power Input Terminal is an essential accessory for the MiLight/Miboxer SYS Series X LED lighting system. It provides a secure and reliable connection between a 24V DC power supply and the lighting system, ensuring stable performance for both commercial and residential installations.

Advantages

This plug-and-play terminal simplifies installation with its screw terminal block for input and a proprietary SYS Series X connector for output. Its compact white design blends seamlessly with the system, and the durable ABS plastic with copper alloy terminals ensures long-lasting connectivity.

Suitable for

• MiLight/Miboxer SYS Series X LED products
• Smart LED lighting systems
• Commercial and residential LED installations

Key specifications

• Input Voltage: DC 24V
• Max Output Current: 6A
• Input Connection: Screw Terminal Block (2 terminals for +24V and GND)
• Output Connection: Proprietary SYS Series X Connector (1 port)
• Material: ABS Plastic, Copper Alloy Terminals
• Color: White
• Operating Temperature: -20°C to 60°C
• Protection Rating: IP20 (Indoor Use)
• Certifications: CE, RoHS
• Compatible Cable Gauge: Up to 18 AWG

Recommendations

For optimal performance, use with a certified 24V DC power supply and ensure proper wiring to the screw terminals. This terminal is designed for indoor use only.
