Tomada de parede MENNEKES Cepex CEE 16A 3 polos 6h 230V IP44 azul 4102

For workshops, garages and industrial facilities that need a reliable 230 V power point, the MENNEKES Cepex wall socket provides a splash-proof CEE connection. Mount it on the wall and plug in equipment with a 6h earth position, and you get a secure 16 A supply for tools, compressors or lighting.

Key specifications

• Current rating: 16 A
• Voltage rating: 230 V
• Number of poles: 3-pole (2P+E)
• Earth contact position: 6h
• Ingress protection: IP44
• Frequency: 50/60 Hz
• Housing material: Polyamide
• Connection technology: Screw terminals
• Mounting type: Wall-mounted
• Colour: Blue
• Series: Cepex
• Standards compliance: IEC 60309-1, IEC 60309-2
• Cable entry: Multiple (rear, top, bottom)
• Max. conductor cross-section: 2.5 mm²
• Operating temperature range: -25°C to +40°C

Why choose it

The Cepex series is built for daily use in demanding environments. The IP44 rating means it withstands splashing water from any direction, and the polyamide housing resists impact and corrosion. Screw terminals make installation straightforward, and multiple cable entry options give flexibility when wiring.

Ideal use cases

• Powering portable equipment in workshops
• Outdoor use in protected areas like carports or covered terraces
• Connecting machinery in agricultural buildings
• Replacing worn sockets in existing installations

Good to know

The socket is rated for 50/60 Hz and accepts conductors up to 2.5 mm². It operates in temperatures from -25°C to +40°C, making it suitable for unheated spaces.
