Tomada tipo F + USB A + USB C Bachmann 946.204 aço inoxidável

The Bachmann 946.204 is a compact desktop-embedded power unit in stainless steel that combines a Type F socket with USB A and USB C ports. Designed for integration into kitchen worktops, desks and office furniture, it has a shallow mounting depth and a removable cover for easier cleaning. The unit opens automatically at the push of a button and can be closed manually; an anti-fingerprint coating keeps the visible surface free of marks. Dimensions: 115 × 115 × 42.5 mm; maximum desktop thickness 40 mm; protection class IP20.

Advantages

The device offers a space-saving, elegant stainless steel finish with a square design and high-quality surfaces. Fast charging is supported via the integrated 22 W USB A/C charger. Its low mounting depth (approx. 40 mm) allows installation above drawers and in thin worktops, while the automatic-opening mechanism and removable cover improve everyday convenience and maintenance. The anti-fingerprint coating reduces visible smudges.

Suitable for

• Kitchen worktops and islands
• Office desks and meeting tables
• Home offices and living room furniture
• Workspaces requiring combined mains and fast USB charging

Key specifications

• Model: Bachmann 946.204
• Body material: Stainless steel
• Connections: 1 × Type F socket, 1 × USB A, 1 × USB C
• USB output: 22 W (USB A/C charger)
• Dimensions (W×D×H): 115 × 115 × 42.5 mm
• Maximum desktop thickness: 40 mm
• Mounting depth: approx. 40 mm
• Protection rating: IP20
• MPN: 946.204
• EAN: 4057298129056

How to use

Press the button to open the unit and access the Type F socket and the USB A/C ports. Connect devices as required; close the cover manually after use to protect the outlets and maintain a tidy surface. For installation, cut an opening in the worktop matching the product dimensions and insert the unit until the housing sits flush. Route the power cable close to the housing and secure the unit according to the included installation instructions. Ensure the desktop thickness does not exceed 40 mm.

Recommendations

Install the unit where the shallow mounting depth (≈40 mm) is sufficient and avoid locations exposed to water; IP20 protects against solid objects but not moisture. Clean the removable cover with a soft, damp cloth to preserve the anti-fingerprint coating and remove the cover for deeper cleaning when necessary.
