Tomada tipo F + USB A + USB C Bachmann 946.205 aço inoxidável

The Bachmann TWIST 2 (model 946.205) is a compact, stainless steel desktop socket-outlet combining a Type F power receptacle with USB-A and USB-C charging ports. Designed for embedding in worktops and desks up to 40 mm thick, the unit has a low installation depth of around 40 mm, an IP20 indoor rating and a removable cover for easier cleaning. The stainless steel surface includes an anti-fingerprint coating and the square TWIST 2 offers an automatic-opening cover that can also be closed manually after use.

Advantages

The TWIST 2 provides an elegant, space-saving solution for kitchens, living rooms and offices with a compact footprint (115 x 115 x 42.5 mm) and close-routed power cable for convenient installation above drawers. Its high-quality stainless steel surfaces, anti-fingerprint finish and removable cover improve hygiene and appearance. An automatic opening mechanism activated by a push-button enhances usability while the integrated 22 W USB-A/C charger enables fast device charging.

Suitable for

• Embedding in kitchen worktops and islands
• Desks and office workstations requiring power and fast USB charging
• Living room furniture or media cabinets with indoor power needs

Key specifications

• Manufacturer: Bachmann, model 946.205
• Material and finish: Stainless steel with anti-fingerprint coating
• Socket types: Type F mains outlet + USB-A + USB-C ports
• USB charger power: 22 W (USB-A/C combined)
• Dimensions (W × D × H): 115 × 115 × 42.5 mm
• Maximum countertop thickness for embedding: 40 mm
• Installation depth: approximately 40 mm
• Protection rating: IP20 (indoor use)
• EAN: 4057298129063

How to use

Cut a mounting hole in the worktop according to the product’s installation dimensions and route the power cable close to the housing. Insert the TWIST 2 into the cutout and secure it according to the manufacturer’s installation instructions. Press the push-button to open the cover automatically; after use, close the cover by hand. Plug mains-powered devices into the Type F outlet and connect USB devices to the USB-A or USB-C ports for charging.

Recommendations

Install the TWIST 2 in dry, indoor environments only (IP20). Ensure the worktop or desk does not exceed the maximum embedding thickness of 40 mm and that the mounting depth fits existing drawers or fittings. Clean the stainless steel surface with a soft, non-abrasive cloth to preserve the anti-fingerprint coating.
