Unitech MS633 - Leitor de códigos de barras - portátil - LR

Slow, error-prone manual data entry at the point of sale or in inventory management creates bottlenecks and costly mistakes. The Unitech MS633 handheld barcode scanner eliminates these issues with fast, accurate 1D barcode reading in a rugged, ergonomic design.

Who is it for

Retail associates, warehouse staff, and logistics teams who need a dependable wired scanner for high-volume scanning of standard 1D barcodes. It suits environments where mobility is not required but reliability and speed are critical.

Main features

• Linear CCD scan engine with 200 scans/second for rapid data capture
• Reads all common 1D symbologies including UPC/EAN, Code 39, Code 128, GS1 DataBar
• Selectable interfaces: USB, RS-232, or Keyboard Wedge via interchangeable cables
• Durable construction withstands drops from 1.5 m to concrete
• IP42-rated against dust and water spray
• Visible red LED aimer for precise targeting
• Programmable beeper and LED indicators for scan confirmation
• Wide operating temperature range (0°C to 50°C) and high ambient light immunity (100,000 lux)

Specifications

• Scanner type: Handheld barcode scanner
• Scan engine: Linear CCD imager
• Decoding capability: 1D barcodes (UPC/EAN, Code 39, Code 128, GS1 DataBar, etc.)
• Scan rate: 200 scans/second
• Depth of field: Up to 300 mm (13 mil UPC/EAN)
• Minimum resolution: 4 mil (Code 39)
• Light source: 630 nm visible red LED
• Reading angle: Pitch ±60°, Skew ±60°
• Connectivity: Wired (USB, RS-232, Keyboard Wedge)
• Power input: 5V DC
• Drop specification: 1.5 m to concrete
• IP rating: IP42
• Operating temperature: 0°C to 50°C
• Storage temperature: -20°C to 60°C
• Humidity: 5% to 95% non-condensing
• Ambient light immunity: Up to 100,000 lux
• Indicators: LED, programmable beeper
• Colour: Black/Grey

Tips

Pair the MS633 with a hands-free stand (sold separately) for presentation scanning at checkout counters. Use the keyboard wedge interface for quick integration with legacy systems without driver installation.
