VOLTAGE VEC12020 12V 1.66A 20W IP67 Fonte de alimentação comutada hermética em caixa

Outdoor and damp-location low-voltage installations often fail because standard power supplies cannot withstand moisture, dust, or temperature swings. The VOLTAGE VEC12020 solves this with a fully sealed IP67 enclosure that shrugs off rain, splashes, and dust while delivering stable 12V DC power. Its compact 50mm round body fits directly into standard junction boxes, making it ideal for LED lighting, garden fixtures, and other 12V devices that need reliable, protected power.

Who is it for

Electricians, lighting installers, and DIY enthusiasts who need a dependable power source for outdoor LED strips, landscape lights, or any low-voltage device in wet or dusty environments. It is also perfect for retrofits where space is tight and a flush-mounted, in-box solution is required.

Main features

• Hermetic IP67-rated housing: fully protected against dust and temporary immersion, safe for outdoor and damp locations.
• Constant 12V DC output at 1.66A (20W), suitable for a wide range of LED and low-voltage devices.
• Compact 50mm diameter design fits standard junction boxes, enabling clean, hidden installations.
• Wide input range 100-240V AC, 50/60Hz, works with mains power worldwide.
• Built-in protections against overload, short circuit, over voltage, and over temperature for long-term reliability.
• Fanless natural convection cooling: silent operation with no moving parts to fail.
• Pre-wired input and output leads for quick, hassle-free connection.
• High efficiency (>80%) reduces energy waste and heat generation.

Specifications

• Product type: Switching power supply
• Output voltage: 12V DC
• Output current: 1.66 A
• Output power: 20 W
• Input voltage: 100-240V AC
• Input frequency: 50/60 Hz
• Ingress protection: IP67
• Diameter: 50 mm
• Cooling: Natural convection (fanless)
• Output type: Constant voltage (CV)
• Protections: Overload, short circuit, over voltage, over temperature
• Efficiency: >80%
• Operating temperature: -20°C to +50°C
• Housing material: High-grade plastic
• Certifications: CE, RoHS
• Mounting type: Flush mount / built-in (for junction boxes)
• Wiring: Pre-wired input/output leads
• Dimming capability: No

Tips

Always verify that the total wattage of your connected LED strip or device does not exceed 20W to avoid overloading. For outdoor installations, ensure the junction box is also rated for wet locations and that cable glands or sealants are used to maintain the IP67 integrity. If you need to power multiple fixtures, consider using a higher-wattage supply or splitting the load across multiple units.
