Adaptador OM Rittal SV 9340.310, adaptador de painel poliamida cinzento, (L x A) 45 x 208 mm, para espessura de barramento 5 mm

Rittal OM-Adapter SV 9340.310 is a grey polyamide adapter designed to support and secure flat busbars in electrical enclosures and distribution systems. With overall dimensions of 45 x 208 mm (width x height) and a profile made for a 5 mm thick busbar, this adapter provides mechanical fixation and electrical insulation where reliable mounting is required. The polyamide material (RAL 7035) offers dimensional stability and resistance to common environmental influences encountered in indoor electrical installations.

Advantages

The adapter combines mechanical strength and insulating properties to support busbars without introducing conductive paths. Its standardized rectangular form factor and compact size make it simple to integrate into existing enclosures and mounting systems. The use of polyamide ensures chemical resistance, low moisture absorption and good long-term durability under normal operating conditions.

Suitable for

Key specifications

How to use

Position the adapter on the intended mounting surface or within the enclosure so the busbar rests securely in the adapter profile. Ensure the adapter aligns with the busbar run and any mounting holes or fixation points on the enclosure. Insert the 5 mm thick busbar into the adapter and secure with appropriate fasteners according to the enclosure and application requirements. Confirm that the adapter provides continuous support along the busbar and that electrical clearances comply with applicable standards.

Recommendations

Use the adapter only with busbars of the specified 5 mm thickness and inspect mounting surfaces for flatness and stability prior to installation. Follow relevant electrical safety standards and enclosure manufacturer guidelines when positioning and fastening the adapter to maintain required creepage and clearance distances.
