Alicate METZ CONNECT 140301-E comprimento das garras 4,6 cm comprimento 180 mm altura 39 mm

Plier METZ CONNECT 140301-E with a jaw length of 4.6 cm, overall length 180 mm and height 39 mm. This adjustable parallel-jaw pliers is designed to compress C6Amodul, E‑DAT modul, E‑DAT Industry field jack and E‑DAT Industry field plug. The tool combines precise jaw alignment with robust construction for reliable performance in electronics and electrical installation tasks.

Advantages

The parallel-jaw design provides uniform pressure across the contact area to ensure consistent compression. The adjustable mechanism allows precise setting of jaw spacing for different modules and plugs. Compact dimensions (jaw length 4.6 cm, total length 180 mm) and an ergonomic handle enable controlled operation and comfortable use during extended work periods.

Suitable for

• Compression of C6Amodul connectors
• Crimping and compression of E‑DAT modul
• Assembly and field termination of E‑DAT Industry field jack
• Compression of E‑DAT Industry field plug

Key specifications

• Brand: BTR
• Manufacturer part number (MPN): 140301-E
• EAN: 4250184115489
• Jaw length: 4.6 cm
• Total length: 180 mm
• Height: 39 mm
• Type: Adjustable parallel-jaw pliers for connector compression

How to use

Position the connector or module between the parallel jaws, set the adjustable mechanism to the required spacing and apply steady pressure until the connector is compressed evenly. Ensure the part to be compressed is seated correctly in the jaw profile before completing the operation. Release the jaws and inspect the compression to confirm correct engagement and contact alignment.

Recommendations

Use the pliers on compatible METZ CONNECT modules and E‑DAT components only. Inspect the jaws for wear before use and avoid excessive force beyond normal compression to prevent damage to the connector or the tool.
