APC Service Bypass Panel PDU 230V 16A 3000VA 2U para rack preto

The APC Service Bypass Panel is a professional-grade power distribution unit designed to provide safe and convenient maintenance bypass for UPS systems. This 2U rack-mountable PDU allows you to isolate your UPS for service or replacement without interrupting power to connected equipment. With a nominal power capacity of 3000 VA / 3680 W and support for 230V input and output at 16A, it is ideal for data centers, server rooms, and network closets requiring high availability.

Advantages

Enables hot-swap maintenance of UPS systems, reducing downtime during service. Manual bypass operation provides a simple and reliable method to keep critical loads powered. Compact 2U design saves valuable rack space. Hardwired input and output connections ensure secure and permanent installation.

Suitable for

• Data centers requiring UPS maintenance without power interruption
• Server rooms with APC Smart-UPS and Symmetra models
• Network closets needing reliable power distribution and bypass capability

Key specifications

• Input Voltage: 230V AC
• Output Voltage: 230V AC
• Input Current: 16A
• Output Current: 16A
• Power Capacity: 3000 VA / 3680 W
• Input Connection: Hardwire
• Output Connection: Hardwire (3-wire HN+G) and 1x IEC C19
• Form Factor: 2U Rack-mountable
• Colour: Black
• Dimensions (WxDxH): 43.2 cm x 7.6 cm x 8.9 cm
• Weight: 2.3 kg
• Operating Temperature: 0°C to 40°C
• Operating Humidity: 0% to 95% (non-condensing)
• Certifications: CE, VDE, IEC 60950

Recommendations

This service bypass panel is designed for use with select APC UPS models including SMT2200I-AR, SMT3000I-AR, SRT1500XLA, SRT2200XLI, SRT3000XLI, and others. Ensure compatibility with your UPS model before purchase. Professional installation recommended.
