BCS LINE BCS-L-AD23 Fonte de alimentação 12V 2A 24W preto

The BCS LINE BCS-L-AD23 is a high-quality switching power adapter designed to provide reliable and efficient power conversion for a wide range of electronic devices. With an input voltage range of 100-240V AC and a regulated output of 12V DC at 2A (24W), this adapter ensures stable performance across various global power standards. Its compact design and black ABS plastic housing make it suitable for both home and office use.

Advantages

This adapter features Level VI energy efficiency, reducing power consumption and heat generation. It includes multiple protection features such as overload, short circuit, and over voltage protection, ensuring the safety of connected devices. The 1.2-meter output cable with a standard DC barrel jack (5.5mm outer diameter, 2.1mm inner diameter, center positive) offers flexibility in placement.

Suitable for

• LED strips and lighting systems
• Security cameras and CCTV equipment
• Routers, switches, and networking devices
• Audio/video equipment
• Other 12V DC powered devices up to 24W

Key specifications

• Brand: BCS
• Model: BCS-L-AD23
• Input: 100-240V AC, 50/60Hz
• Output: 12V DC, 2A, 24W
• Connector: DC barrel jack 5.5x2.1mm, center positive
• Input plug: EU Type C/F
• Cable length: 1.2 meters
• Efficiency: Level VI
• Protection: Overload, short circuit, over voltage
• Housing: ABS plastic, black
• Certifications: CE, RoHS
• Operating temperature: 0°C to 40°C

Recommendations

Ensure that the device you intend to power requires 12V DC and does not exceed 2A (24W). Verify the polarity and connector size before use. This adapter is not suitable for outdoor use unless properly protected from moisture.
